Telemecanique XS112BLPBM12 Osisense Proximity Sensor
Part Number # XS112BLPBM12
SKU # 2435600
$43.64 / Each
Telemecanique XS112BLPBM12 Key Features
| Brand: | Telemecanique |
|---|---|
| Part Number # : | XS112BLPBM12 |
| SKU #: | 2435600 |
| Amperage Rating: | <=200 mA |
| Contact Configuration: | 1NC |
| Enclosure Type: | IP65/IP67 |
| Environmental Conditions: | -40 to 185 deg F Storage/50 gn Shock Resistance |
| Frequency Response: | <=2500 Hz |
| Interface: | 3-Wire |
| Response Time: | 0.1 ms |
| Sensing Distance: | 0.08 in |
| Sensing Method: | Inductive |
| Sensing Position: | Front |
| Series: | XS1 Series |
| Size: | 55 mm L x 12 mm H |
| Temperature Rating (Degrees F): | -25 to 70 deg C |
| Type: | Cylindrical Fixed Form |
| Connection type: | 4-Pin M12 Male |
| Country of origin: | ID |
| Material: | Nickel Plated Brass |
| Mounting type: | Flush |
| Output type: | Discrete/PNP, PNP/Discrete |
| Manufacturer Name: | YAGEO Corporation |
| UNSPSC: | 39122230 |
| UPC: | 00785901480990 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$43.64 / Each
Quantity:
- Telemecanique OsiSense Proximity Sensor, Cylindrical Fixed Form, Series: XS1 Series, Inductive Sensing Method, 0.08 in Sensing Distance, Front Sensing Position, 10 Output, 1NC, 12 to 24 V DC, <=200 mA, <=2500 Hz, 4-Pin M12 Male, 0.1 ms Response, 3-Wire Interface, 55 mm L x 12 mm H, IP65/IP67, -25 to 70 deg C, Flush Mount, Nickel Plated Brass, Environmental Conditions: -40 to 185 deg F Storage/50 gn Shock Resistance
XS112BLPBM12 Application
General purposeXS112BLPBM12 Item Features
- Tested for use in very harsh environments, beyond standard requirements
- Specifically, application tests conducted in an environment prone to interference, in the vicinity of variable speed drives or motors, demonstrated very good EMC immunity
XS112BLPBM12 Standards
CSA Certified|RoHS Compliant|UL Listed|CE Certified|PROP65: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP) and Diisononyl phthalate (DINP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov|IEC 60068-2-27|IEC 60529|IEC 60947-5-2|REACH CompliantSKU #2435600Part Number #XS112BLPBM12UNSPSC39122230UPC00785901480990
