Telemecanique XS4P08PC410 Osisense Proximity Sensor

Brand: Telemecanique

Part Number: XS4P08PC410

Telemecanique OsiSense® Proximity Sensor, Cylindrical Fixed Form, Series: XS4 Series, Inductive Sensing Method, 0.08 in Sensing Distance, Front Sensing Position, Discrete/PNP Output, 1NC-1NO Contact Configuration, 12 to 24 VDC, <=200 mA, <=5000 Hz Frequency Response, 2 m Cable Connection, 0.1 ms Response, 4-Wire Interface, 50 mm L x 8 mm H Size, IP67 Enclosure, -25 to 70 deg C, PPS, Environmental Conditions: -40 to 185 deg F Storage/50 gn Shock Resistance

Additional Description: TELE-XS4P08PC410 (N) INDUCTIVE SENSOR 24VDC 200MA XS +OPTIONS inductive sensor XS4 M8, L50mm, PPS, Sn2mm, 12...24 VDC, cable 2 m NON-CANCELABLE, NON-RETURNABLE

Catalog Description: The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a cylindrical, non flush mountable sensor. Diameter 8mm, threaded M8 x 1. It features a plastic case and a 2m long cable. It has a sensing distance of 2.5mm. Four-wire, DC supply, 12V to 24V, NO + NC function, PNP solid-state output .
