Thomas & Betts 210219 Sta-Kon Ring Terminal
Part Number # 210219
SKU # 2220438
Thomas & Betts 210219 Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | 210219 |
| SKU #: | 2220438 |
| Barrel Size: | 0.56 in L x 0.38 in W |
| Conductor Size: | 14 to 10 AWG |
| Conductor Type: | Aluminum/Copper |
| Finish: | Tin Plated |
| Specifications: | 0.08 to 0.09 in THK, 4110 to 20760 kcmil |
| Tongue Size: | 0.41 in W |
| Tongue Type: | Ring |
| Type: | Insulation Piercing Magnet Wire |
| Country of origin: | US |
| Length: | 1.22 in |
| Material: | Copper |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121432 |
| UPC: | 00786210839653 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Thomas & Betts 210219 Sta-Kon Ring Terminal
Brand: Thomas & Betts
Part Number: 210219
Dragon Tooth Ring Terminal, Insulation Piercing Magnet Wire, Aluminum/Copper Conductor, 14 to 10 AWG Conductor, #8 Stud, 1.22 in Length, 0.56 in L x 0.38 in W Barrel, Ring Tongue, 0.41 in W Tongue, Specifications: 0.08 to 0.09 in THK, 4110 to 20760 kcmil, Copper, Tin Plated
Additional Description: TB -210219 (N) RING TERM CU 14-10 AWG No8 STUD .38X.5 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Insulation Piercing Magnet Wire Ring Terminal, Length 1.22 Inches, Width .41 Inches, Length of Teeth .56 Inches, Width of Teeth .38 Inches, Stud Size 8, Wire Range #14 AWG - #10 AWG 4,110 Circular Mil Area - 20,760 Circular Mil Area, Copper Alloy, Tin Plated
210219 Application
For aluminum to copper, aluminum to aluminum or copper to copper magnet wire connections210219 Includes
Male and Female 0.25 x 0.032 in Disconnect210219 Item Features
- Designed to penetrate magnet wire insulation during application, eliminating the need for stripping, brazing, welding or other methods of joining magnet wire
- Can be installed in seconds
- Requires minimal training for installation
- Supplied with bolt holes to accommodate #6 through 1/2 in studs
210219 Standards
UL File No. E9809SKU #2220438Part Number #210219UNSPSC39121432UPC00786210839653
