Part Number # 256-30695-1355
SKU # 2456342
Image Disclaimers Message
256-30695-1355
Thomas & Betts 256-30695-1355
Part Number # 256-30695-1355
SKU # 2456342
Thomas & Betts 256-30695-1355 Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | 256-30695-1355 |
| SKU #: | 2456342 |
| Barrel Size: | 0.41 in Dia |
| Barrel Type: | Standard |
| Conductor Size: | 2 AWG |
| Conductor Type: | Copper |
| Overall Length: | 2.15 in |
| Specifications: | 3/4 in Hole Spacing, Tin Plated Finish |
| Temperature Rating (Degrees F): | 90 deg C |
| Tongue Size: | 1.31 in L x 0.594 in W x 0.13 in THK |
| Tongue Type: | Straight |
| Type: | 2-Hole |
| Color: | Brown |
| Country of origin: | MX |
| Material: | Copper |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121405 |
| UPC: | 00786210886190 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Thomas & Betts 256-30695-1355
Brand: Thomas & Betts
Part Number: 256-30695-1355
Color-Keyed® Compression Connector Lug, 2-Hole, Copper Conductor, 2 AWG Conductor, Die Code: 33, 35 kVAC, 1/4 in Stud, Straight Tongue, 1.31 in L x 0.594 in W x 0.13 in THK Tongue, 2.15 in Overall Length, Standard Barrel, 0.41 in Dia Barrel, 3/4 in Hole Spacing, Tin Plated Finish, 90 deg C, Copper, Brown
Additional Description: TB -256-30695-1355 (N) CU TP 2HL LUG STD BRL No2 1/4B BRN NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Copper Two-Hole Lug, Standard Barrel, Peep Hole, Max 35kV, Wire Size #2 AWG, 1/4 Inch Bolt Size, 3/4 Inch Hole Spacing, Tin Plated, Die Color Code Brown, Die Code 33
256-30695-1355 Application
For copper conductor applications256-30695-1355 Item Features
- High conductivity electro wrought copper construction
- Standard marking, round hole
- 1/4 in hole center to end
- 3 AWG, 60 navy, 125/24, 4 weld (Classes G, H, I, K, M) flex cable size
- High conductivity wrought copper electro-tin-plated finish
- Peep hole, standard marking, round hole
256-30695-1355 Standards
UL File No. E9809|CSA CertifiedSKU #2456342Part Number #256-30695-1355UNSPSC39121405UPC00786210886190
