Thomas & Betts 256-30695-840 Color-Keyed Compression Connector Lug
Thomas & Betts 256-30695-840 Color-Keyed Compression Connector Lug
Part #:256-30695-840
SKU #: 2250382
Key Features
Part #:256-30695-840
SKU #: 2250382
Brand: Thomas & Betts
Barrel Size: 1-1/2 in Dia
Barrel Type: Standard
Conductor Size: 700, 700 kcmil
Conductor Type: Copper
Overall Length: 4, 4 in
- High conductivity wrought copper construction
- 13/16 in hole to tongue end
Thomas & Betts 256-30695-840 Color-Keyed Compression Connector Lug
Color-Keyed Compression Lug Connector, 1-Hole Non-Insulated, Copper Conductor, 700 kcmil Conductor, Die Code: 99, 35 kV, 1/2 in Stud, 1.69 in L x 1.81 in W x 0.28 in THK Tongue, 4 in Overall Length, Standard Barrel, 1-1/2 in Dia Barrel, Specifications: 13/16 in Stud Hole Spacing, Tin Plated, Copper, Pink
Additional Description: TB -256-30695-840 (N) 535 CU STD. BRL. 1 HOLE 1/2 IN BOLT NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Copper One-Hole Lug, Standard Barrel, Peep Hole, Max 35kV, Wire Size 700 kcmil, 1/2 Inch Bolt Size, 13/16 Inch Hole Spacing, Tin Plated, Die Color Code Pink, Die Code 99
