Thomas & Betts 54610 Color-Keyed Wire Joint
Thomas & Betts 54610 Color-Keyed Wire Joint
Part #:54610
SKU #: 2202113
Key Features
Part #:54610
SKU #: 2202113
Brand: Thomas & Betts
Dimensions: 0.37 in Dia, 0.37 in Dia Base
Finish: Tin Plated
Specifications: 24 Die Code
Suitable For Use With: Copper Conductor, Pigtailing, Tapping Multiple Conductor or 2-Way Splicer
Temperature Rating (Degrees F): 90, 90 deg C
- Offers lowest installed cost
- Form a permanent installation in minimal space, easily insulated
- Color coded to dies for positive matching and compression
- All-around compression ensures high conductivity, low resistance and high pull-out values exceeding CSA requirements
- Application tool TBM25S, TBM8, TBM8S, TBM5, TBM5S, TBM6, TBM6S
- 19590 to 27290 circular mil area
- (3) 12 AWG solid/stranded, (2) 10 AWG with (1) 12 AWG solid/stranded
Thomas & Betts 54610 Color-Keyed Wire Joint
Color-Keyed Wire Joint, 600 VAC, 12 to 10 AWG Wire, 0.407 in Length, 90 deg C, For Use With: Pigtailing, Tapping Multiple Conductor or 2-Way Splicer, Specifications: 24 Die Code, Copper, Blue, Tin Plated, 0.37 in Dia
Additional Description: TB -54610 CONN,CPRSN,CBL JT
Catalog Description: Copper Cable Joint, Wire Range Min: 3 #12 Sol or Str, Max: 2 #10 with 1 #12 Sol or Str, Tin Plated, Blue Die
