Part Number # 750M
SKU # 2167859
Image provided may only be a representation of
final product and may include optional equipment
750M
Thomas & Betts 750M Blackburn Split Bolt Connector
Part Number # 750M
SKU # 2167859
Thomas & Betts 750M Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | 750M |
| SKU #: | 2167859 |
| Conductor Size: | 600 to 750, 600 to 750 kcmil |
| Conductor Type: | Stranded Copper |
| Specifications: | 1.029 in Split, 2-1/4 in Hex Nut |
| Type: | Type H High Strength |
| Country of origin: | MX |
| Material: | Bronze Alloy |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121408 |
| UPC: | 00783786200290 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Thomas & Betts 750M Blackburn Split Bolt Connector
Brand: Thomas & Betts
Part Number: 750M
Blackburn Split Bolt Connector, Type H High Strength, Stranded Copper Conductor, 600 to 750 kcmil Conductor, 1-15/16 x 3-21/32 in Bolt, 1.029 in Split, 2-1/4 in Hex Nut, Bronze Alloy, Metallic
Additional Description: TB -750M H-STRNGTH SPLITBLT CONN 750-600
Catalog Description: Type H - High Strength Split-Bolt Connector, Conductor Range for Equal Main and Tap 750 kcmil-600 kcmil, Conductor Range for Min Tap with One Max Main 4/0 Str
750M Application
For splicing, tapping or terminating conductors in power and grounding electrical connection750M Item Features
- Bolt and nut of high-strength corrosion resistant bronze alloy
- Pressure bar is copper through 40H, copper alloy for 350 kcmil and above
- Bolt and nut of hex design up to 350 kcmil
- Split-bolt connector made of metallic bronze alloy for use on copper conductors
- 4/0 AWG stranded conductor range min tap with one max main
- 750 kcmil to 600 kcmil conductor range for equal main and tap
- 1 Piece/Pack
750M Standards
UL E9809SKU #2167859Part Number #750MUNSPSC39121408UPC00783786200290
