Thomas & Betts ADR60-44D Blackburn Mechanical Connector
Image Disclaimers Message
Thomas & Betts ADR60-44D Blackburn Mechanical Connector
Thomas & Betts ADR60-44D Blackburn Mechanical Connector
Part #:ADR60-44D
SKU #: 399435
Key Features
Part #:ADR60-44D
SKU #: 399435
Brand: Thomas & Betts
Conductor Size: 2 AWG to 600 kcmil
Conductor Type: Aluminum/Stranded Copper
Dimensions: 5-5/16 in L x 5-5/8 in W x 1-1/2 in H
Finish: Tin Plated
Specifications: 4-Conductor, 1-7/16 in Hole Spacing
- Easy installation - no special tools required
- NEMA spacing 1-3/4 in centers
- Connectors accommodating conductors 600 kcmil and larger have double rows of set screws
- Extra aluminum lug
- Tin plated for low contact resistance
- 4 stud of 1/2 in
Thomas & Betts ADR60-44D Blackburn Mechanical Connector
Blackburn Mechanical Connector, Type ADR-ALCUL Dual Rated, Aluminum/Stranded Copper Conductor, 2 AWG to 600 kcmil Conductor, 1/2 in Stud, 4 Bolt Holes, 3-1/16 in L x 5-5/8 in W x 3/8 in THK Tongue, Straight Tongue, Specifications: 4-Conductor, 1-7/16 in Hole Spacing, Aluminum, Tin Plated, 5-5/16 in L x 5-5/8 in W x 1-1/2 in H Dimensions
Additional Description: TB -ADR60-44D AL TP 4CNDTR 4HOLE MOUNT 2-600
Catalog Description: Type ADR-ALCUL Four-Conductor, Four-Hole Mount for Conductor Range Max 600 kcmil, Min 2 Str.
