C36
Thomas & Betts C36 Sta-Kon Ring Terminal
Part Number # C36
SKU # 2180557
$146.20 / 500Each
Thomas & Betts C36 Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | C36 |
| SKU #: | 2180557 |
| Barrel Type: | Serrated |
| Conductor Size: | 12 to 10, 12 to 10 AWG |
| Finish: | TiN Coated |
| Series: | C Series |
| Specifications: | 0.27 in Clearance |
| Temperature Rating (Degrees F): | 150, 150 deg C |
| Tongue Size: | 0.31 in W x 0.04 in THK |
| Tongue Type: | Ring |
| Type: | Non-Insulated |
| Color: | Metallic |
| Country of origin: | US |
| Length: | 0.82, 0.82 in |
| Material: | Copper |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121432 |
| UPC: | 00786210810683 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$146.20 / 500Each
Quantity:
Thomas & Betts C36 Sta-Kon Ring Terminal
Brand: Thomas & Betts
Part Number: C36
Sta-Kon Ring Terminal, Non-Insulated, Series: C Series, 12 to 10 AWG Conductor, #10 Stud, 0.82 in Length, Serrated Barrel, Ring Tongue, 0.31 in W x 0.04 in THK Tongue, 600 VAC, 0.27 in Clearance, 150 deg C, Copper, Tin Coated, Metallic
Additional Description: TB -C36 NON-INS RING TRM 12-10 No10 METAL METALLIC META
Catalog Description: Non-Insulated Ring Terminal, Length .82 Inches, Width .31 Inches, Bolt Hole #10, Wire Range #12-#10 AWG, Copper, Tin Plated, 500 Pack
C36 Application
For WT110M, WT111M, WT112M, WT2000, ERG4002 and ERG4005 toolsC36 Item Features
- Non-insulated ring terminals are made of electrolytic copper for high conductivity/corrosion resistance
- Can be installed with crimping tools having a single indenter or double indenter (recommended for solid wire)
- Serrated barrel to increases grip-on wire
- 500 pieces/pack
C36 Standards
UL Listed|UL 94 V-0 Flammability Rated|CSA Certified|UL File No. E9809SKU #2180557Part Number #C36UNSPSC39121432UPC00786210810683
