Part Number # C480
SKU # 2377759
C480
Thomas & Betts C480 Sta-Kon Ring Terminal
Part Number # C480
SKU # 2377759
Thomas & Betts C480 Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | C480 |
| SKU #: | 2377759 |
| Barrel Type: | Brazed Seam |
| Conductor Size: | 12 to 10 AWG |
| Finish: | TiN Coated |
| Series: | C Series |
| Specifications: | Non-Insulated |
| Temperature Rating (Degrees F): | 150 deg C |
| Tongue Size: | 0.39 in W |
| Tongue Type: | Rectangle |
| Country of origin: | US |
| Length: | 1.27 in |
| Material: | Electrolytic Copper |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121432 |
| UPC: | 00786210811246 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Thomas & Betts C480 Sta-Kon Ring Terminal
Brand: Thomas & Betts
Part Number: C480
Sta-Kon Ring Terminal, Series: C Series, 12 to 10 AWG Conductor, #8 Stud, 1.27 in Length, Brazed Seam Barrel, Rectangle Tongue, 0.39 in W Tongue, 600 V, Specifications: Non-Insulated, 150 deg C, Electrolytic Copper, TiN Coated
Additional Description: TB -C480 (N) NON-INS RECT RING TERM, 12-10, No8 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Non-Insulated Rectangular Ring Terminal, Length 1.27 Inches, Width .390 Inches, Bolt Hole #8, Wire Range #12-#10 AWG, Copper, Tin Plated
C480 Item Features
- Funneled barrel entry, deep internal serrations, brazed or overlapping seams
C480 Standards
BAA Compliant|CSA Certified|UL E9809SKU #2377759Part Number #C480UNSPSC39121432UPC00786210811246
Image provided may only be a representation of final product and may include optional equipment
