Brand: Thomas & Betts
Thomas & Betts DS2504MRAB0 Russellstoll MaxGard Pin and Sleeve Inlet
Image Disclaimers Message
Brand: Thomas & Betts
Thomas & Betts DS2504MRAB0 Russellstoll MaxGard Pin and Sleeve Inlet
Brand: Thomas & Betts
Thomas & Betts DS2504MRAB0 Russellstoll MaxGard Pin and Sleeve Inlet
Part #:DS2504MRAB0
SKU #: 2204100
$3890.64/EA
Key Features
Part #:DS2504MRAB0
SKU #: 2204100
Brand: Thomas & Betts
Amperage Rating: 200, 200 A
Frequency Rating: 50 to 400, 50 to 400 Hz
Number of Poles: 4
Number of Wires: 5
Terminal Type: Screw
$3890.64/EA
- Waterproof construction provides environmental separation at the front of each device
- Two optional pilot/control pins for contractors, load monitor circuits, shunt trip or any other communication functions you need
- Center ground contacts, make first, break last
- Standard delayed action pull and turn withdrawal offers all plugs an XP rating (30-100 amps)
- For use in applications where outdoor, severe or high abuse environments exist
- Copper free, cast aluminum, epoxy powder coated housing
Specifications
Brand: Thomas & Betts
Amperage Rating: 200, 200 A
Frequency Rating: 50 to 400, 50 to 400 Hz
Number of Poles: 4
Number of Wires: 5
Terminal Type: Screw
Voltage Rating: 277/480, 277/480 VAC
Country of origin: MX
Material: Cast Aluminum
Manufacturer Name: ABB
UNSPSC: 39121402
UPC: 00708917157373
Item FeaturesFor electrical hook-up of mobile medical imaging (MMI) trailers, heavy industrial and marine applications
Item Features
Resources
