Part Number # GUA047-G
SKU # 2246627
Image Disclaimers Message
Brand: Thomas & Betts
GUA047-G
Thomas & Betts GUA047-G Ocal Conduit Outlet Box
Part Number # GUA047-G
SKU # 2246627
$394.85 / Each
Typical price:$481.00 / Each
Thomas & Betts GUA047-G Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | GUA047-G |
| SKU #: | 2246627 |
| Capacity: | 29, 29 cu-in |
| Cover Opening Size: | 3.63 in Dia |
| Finish: | PVC Coated |
| Hub Size: | 1-1/4, 1-1/4 in |
| Country of origin: | US |
| Material: | Iron |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121308 |
| UPC: | 00704508383510 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$394.85 / Each
Typical price:$481.00 / Each
Quantity:
Thomas & Betts GUA047-G Ocal Conduit Outlet Box
Brand: Thomas & Betts
Part Number: GUA047-G
Ocal Conduit Outlet Box, 1-1/4 in Hub, 3.63 in Dia Cover Opening, 29 cu-in Capacity, Iron, Gray, PVC Coated
Additional Description: TB -GUA047-G (N) OUTLET BOX PIPE SIZE 1-1/4IN GRAY NON-CANCELABLE, NON-RETURNABLE
Catalog Description: PVC Double-Coated GUA Conduit Outlet Box, Pipe Size 1-1/4 Inch/35 Metric, Box is Ductile Iron with Zinc Plating, Cover is Die Cast Aluminum 29.0 Cubic Inch, Gray
GUA047-G Application
For protect conductors in threaded rigid conduitGUA047-G Item Features
- Double coated, die cast aluminum cover
- Nominal 0.002 in blue urethane coating on both interior and exterior and nominal 0.04 in PVC coating bonded to exterior
- All hubs have a minimum of 5 full threads, integral bushing and Pressure sealing sleeves
- All units furnished with internal grounding screw and ship complete with aluminum cover with O-ring gasket
- Explosion proof, dust ignitionproof, raintight and suitable for use in the following environments
- GUA series conduit boxes are installed in hazardous locations to protect conductors and act as pull and splice box
- Provide access to conductors for maintenance and future system changes
- Mounting outlets for fixtures with proper covers
- To change direction in rigid conduit systems
- Join 2 or more pieces of conduit long run
SKU #2246627Part Number #GUA047-GUNSPSC39121308UPC00704508383510
