Part Number # GUAB24-TB
SKU # 2416396
Image Disclaimers Message
GUAB24-TB
Thomas & Betts GUAB24-TB Conduit Outlet Box
Part Number # GUAB24-TB
SKU # 2416396
$110.37 / Each
Typical price:$147.90 / Each
Thomas & Betts GUAB24-TB Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | GUAB24-TB |
| SKU #: | 2416396 |
| Capacity: | 7.9 cu-in |
| Dimensions: | 2-1/2 in OD |
| Finish: | Zinc Plated |
| Number of Gangs: | 2 |
| Series: | GUAB |
| Size: | 3/4 in |
| Type: | Explosionproof |
| Country of origin: | CN |
| Material: | Ductile Iron |
| Manufacturer Name: | ABB |
| UNSPSC: | 39131708 |
| UPC: | 00786210344393 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$110.37 / Each
Typical price:$147.90 / Each
Quantity:
Thomas & Betts GUAB24-TB Conduit Outlet Box
Brand: Thomas & Betts
Part Number: GUAB24-TB
T&B® Explosionproof Conduit Outlet Box, Series: GUAB, 3/4 in Size, 2 Gangs, 7.9 cu-in Capacity, Ductile Iron, Zinc Plated, 2-1/2 in OD Dimensions
Additional Description: TB -GUAB24-TB (N) 3/4 INCH GUAB-BODY/CVR,O.D.- 2-1/2 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: 3/4 Inch GUAB Hazardous Location Conduit Outlet Box with Cover, Box Ductile Iron Zinc Plated, Cover Die Cast Aluminum, 7.9 Cubic Inch
GUAB24-TB Application
For use to allow mounting of fixture outlets when used with appropriate covers, easy access to wiring, junction in conduit for wire pulling and splices, changes direction in rigid conduit systems, attaches two or more pieces of conduit long runs and guards against damage to wires in rigid conduit and mounting of fixture outlets when used with appropriate covers and wet locationsGUAB24-TB Item Features
- All hubs have a minimum of 5 full threads and integral bushing
- All boxes are furnished with internal grounding screw
- Provides easy access to wiring
- Provides junction in conduit for wire pulling and splices
- Changes direction in rigid conduit systems
- Attaches two or more pieces of conduit long run
- Guards against damage to wires in rigid conduit
- Cover supplied with O-ring gasket
- Die cast aluminum cover with natural finish
- Dust, ignitionproof and raintight
- 0.755 to 0.81 in Dia throat
- Zinc plated with aluminum acrylic paint boxes
- Grade 60-45-10 ductile iron bodies and cast aluminum covers
GUAB24-TB Standards
Class I, Division 1, 2 Group C, D|Class II, Division 1, Group E, F, G|Class III, Division 1, 2|CSA Certified|NEMA 3/4/7/CD/9/EFG|UL File No. E202368SKU #2416396Part Number #GUAB24-TBUNSPSC39131708UPC00786210344393
