Thomas & Betts MS216A Pos-E-Kon Terminal Insert
Image Disclaimers Message
Thomas & Betts MS216A Pos-E-Kon Terminal Insert
Thomas & Betts MS216A Pos-E-Kon Terminal Insert
Part #:MS216A
SKU #: 39588
Key Features
Part #:MS216A
SKU #: 39588
Brand: Thomas & Betts
Number of Positions: 16
Series: A Series
Specifications: 10/16 A, 600 VAC
Suitable For Use With: A Series Connector
Temperature Rating (Degrees F): -40 to 257, -40 to 257 deg F
- 16-contact with ground
- Integral screw terminal contacts that provide for easy terminal wiring and fast assembly
- Standard wire protection saddles prevent cutting of strands during assembly
- Small, compact size screw terminal
- Use small blade screwdriver to push wire entry tab in for easy contact removal
Thomas & Betts MS216A Pos-E-Kon Terminal Insert
Pos-E-Kon Terminal Insert, Compact, Series: A Series, 16 Positions, 20 to 14 AWG Wire, Male Screw Connection, For Use With: A Series Connector, -40 to 257 deg F, Specifications: 10/16 A, 600 VAC, Glass Filled Thermoplastic
Additional Description: TB -MS216A MALE INSERT SCREW, A SERIES W/GND INSERT W/SCREW TERMINALS
Catalog Description: Male screw terminal insert. For use with A series, 16 contacts with ground.
