Brand: Thomas & Betts
Thomas & Betts MS248B Pos-E-Kon Terminal Insert
Image Disclaimers Message
Brand: Thomas & Betts
Thomas & Betts MS248B Pos-E-Kon Terminal Insert
Brand: Thomas & Betts
Thomas & Betts MS248B Pos-E-Kon Terminal Insert
Part #:MS248B
SKU #: 2177481
$63.24/EA
Key Features
Part #:MS248B
SKU #: 2177481
Brand: Thomas & Betts
Number of Positions: 48
Series: B Series
Specifications: 16 A, 600 VAC
Suitable For Use With: B Series Connector
Temperature Rating (Degrees F): -40 to 257, -40 to 257 deg F
$63.24/EA
- 48 contacts with ground
- Integral screw terminal contacts that provide for easy terminal wiring and fast assembly
- Allows single access direction panel build wiring and easy terminal ID for service and testing
- Standard wire protection saddles prevent cutting of strands during assembly
- Standard size screw terminal
- Use small blade screwdriver to push wire entry tab in for easy contact removal
Specifications
Brand: Thomas & Betts
Number of Positions: 48
Series: B Series
Specifications: 16 A, 600 VAC
Suitable For Use With: B Series Connector
Temperature Rating (Degrees F): -40 to 257, -40 to 257 deg F
Type: Standard
Wire Size: 20 to 14, 20 to 14 AWG
Connection type: Male Screw
Country of origin: DE
Material: Glass Filled Thermoplastic
Manufacturer Name: ABB
UNSPSC: 39121410
UPC: 00786210118703
Thomas & Betts MS248B Pos-E-Kon Terminal Insert
Pos-E-Kon Terminal Insert, Standard, Series: B Series, 48 Positions, 20 to 14 AWG Wire, Male Screw Connection, For Use With: B Series Connector, -40 to 257 deg F, Specifications: 16 A, 600 VAC, Glass Filled Thermoplastic
Additional Description: TB -MS248B MA SCR TERM INSERT B SERIES 48CNT
Catalog Description: Male screw terminal insert. For use with B series, 48 contacts with ground.
Item FeaturesFor panel base applications
Item Features
Item FeaturesCSA Certified|UL 94 V-0 Flammability Rated
