Thomas & Betts NVNZ-M406S-13 PMA PMAFIX Conduit Connector
Part Number # NVNZ-M406S-13
SKU # 2313826
NVNZ-M406S-13
Thomas & Betts NVNZ-M406S-13 PMA PMAFIX Conduit Connector
Part Number # NVNZ-M406S-13
SKU # 2313826
Thomas & Betts NVNZ-M406S-13 Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | NVNZ-M406S-13 |
| SKU #: | 2313826 |
| Cable Openings: | 19 to 27 mm |
| Dimensions: | 99 mm L |
| Material: | Nylon/Polyamide 6 |
| UNSPSC: | 39121420 |
| UPC: | 00786209964946 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Thomas & Betts NVNZ-M406S-13 PMA PMAFIX Conduit Connector
Brand: Thomas & Betts
Part Number: NVNZ-M406S-13
PMA PMAFIX Conduit Connector, Reinforced Straight, NW36, Cable Openings: 19 to 27 mm, 55 mm Dia, For Use With: PMAFLEX, PMAFLEX Pro and PMA Smart Line Nylon Flexible Conduits, Nylon/Polyamide 6, Black, 99 mm L
Additional Description: TB -NVNZ-M406S-13 (N) FTNG STR M40 NW36 PA6/BR W/INS 13MM NON-CANCELABLE, NON-RETURNABLE
Catalog Description: VNZ Connector Straight, Metric Metal Thread with Strain Relief IP68 - Thread M40x1.5, Conduit Size NW 36, Thread Length 13, with Sealing Insert, Color Black
NVNZ-M406S-13 Application
For railway vehicle, heavy machine construction and separation of damp/dry areasNVNZ-M406S-13 Includes
Sealing Insert and IP68 Strain ReliefNVNZ-M406S-13 Item Features
- Very high impact resistance
- Integrated strain relief and optimal ingress protection at the cable (up to IP68/10 bar)
- High thread and system connection strength
- Vibrationproof connection to PMAFLEX conduits
- Easy assembly, high conduit pullout strength, very good chemical properties, polyamide-free from halogens and cadmium, excellent impact strength
- Fits fine (T) and coarse (G) conduit profiles
- High grade, specially formulated polyamide 6, thread made of nickel plated brass, sealing inserts are made from TPE-V
- M40x1.5 thread size
- -40 to 105 deg C operating temperature, 160 deg C short temperature
- IP68 insulation class
- 13 mm L thread
NVNZ-M406S-13 Standards
CSA Certified|UL ListedSKU #2313826Part Number #NVNZ-M406S-13UNSPSC39121420UPC00786209964946
