Thomas & Betts TV10-10F-L Sta-Kon Fork Terminal
Part Number # TV10-10F-L
SKU # 2225889
$21.29 / 50Each
Thomas & Betts TV10-10F-L Key Features
Brand: Thomas & Betts
Part Number # TV10-10F-L
SKU #2225889
Barrel Size: 0.134 in ID x 0.252 in OD
Barrel Type: Brazed Seam/Funnel Entry/Internal Serration, Brazed Seam/Serrated
Conductor Size: 12 to 10, 12 to 10 AWG
Finish: Electro-TiN Plated, Electroplated Tin
Series: T Series
Specifications: 0.21 in Dia Maximum Insulation, Vinyl Insulation, Funnel Entry Barrel Configuration, 0.21 in Dia Vinyl Insulation
Temperature Rating (Degrees F): 75, 75 deg C
Tongue Size: 0.375 in W x 0.039 in THK
Tongue Type: Fork
Type: Insulated
Voltage Rating: 600, 600 V
Color: Yellow
Country of origin: TW
Length: 1.025, 1.025 in
Material: Copper
Manufacturer Name: ABB
UNSPSC: 39121432
UPC: 00786209937384
$21.29 / 50Each
Thomas & Betts TV10-10F-L Sta-Kon Fork Terminal
Brand: Thomas & Betts
Part Number: TV10-10F-L
Catamount Fork Terminal, Series: T Series, 12 to 10 AWG Conductor, #10 Stud, 1.025 in Length, Brazed Seam/Funnel Entry/Internal Serration Barrel, 0.134 in ID x 0.252 in OD Barrel, Fork Tongue, 0.375 in W x 0.039 in THK Tongue, 600 V, Specifications: 0.21 in Dia Vinyl Insulation, 75 deg C, Copper, Electro-Tin Plated, Yellow
Additional Description: TB -TV10-10F-L VINYL INSUL FORK TERMINAL 12-10No10
Catalog Description: Vinyl Insulated Fork Terminal, Length 1.025 Inches, Width .375 Inches, Maximum Insulation .210, Bolt Size #10, Wire Range #12-#10 AWG, Color Yellow, Copper, Tin Plated
TV10-10F-L Item Features
- Molded funnel entry insulator
- Internal barrel serrations
- WT112M, CM2000A recommended tools
TV10-10F-L Standards
CSA Certified|UL94 V-0 Flammability Rated|UL File No. E9809SKU #2225889Part Number #TV10-10F-LUNSPSC39121432UPC00786209937384
