Brand: Thomas & Betts
Thomas & Betts UYR02 Homac Service Entrance Splice
Part Number # UYR02
SKU # 2339132
$1170.00 / 500Each
$1570.00/Each
Thomas & Betts UYR02 Key Features
Brand: Thomas & Betts
Part Number # UYR02
SKU #2339132
Conductor Size: 1/0 AWG End A, 2 to 1 AWG End B, 1/0 AWG, 2 to 1 AWG
Conductor Type: ACSR/Stranded, ACSR/Stranded Aluminum
Connector Type: Compression
Specifications: 2-Conductor, Yellow End A/Red End B Die Code, Insulated, Yellow End A/Red End B Die Code, (2) Conductors
Type: Insulated
Voltage Rating: 600, 600 V
Color: Red/Yellow
Country of origin: US
Length: 2-25/32, 2-25/32 in
Manufacturer Name: ABB
UNSPSC: 39121449
UPC: 00783786756032
$1170.00 / 500Each
$1570.00/Each
Thomas & Betts UYR02 Homac Service Entrance Splice
Brand: Thomas & Betts
Part Number: UYR02
Blackburn Service Entrance Splice, Insulated, ACSR/Stranded Aluminum Conductor, 1/0 AWG, 2 to 1 AWG Conductor, Die Code: 5/8, 2-25/32 in Length, Compression Connector, 600 V, Specifications: 2-Conductor, Yellow End A/Red End B Die Code, Aluminum, Red/Yellow
Additional Description: TB -UYR02 AL SERVENTR COMP SPLICE 1/0 2 2-3/4
Catalog Description: Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 1/0 ACSR, 1/0, Red, End B: 2 ACSR, 1-2 Stranded, Red, Die: 5/8.
UYR02 Application
For standard conductorsUYR02 Item Features
- 1/0 AWG ACSR conductor A, 2 AWG ACSR, 2 to 1 AWG stranded conductor B
UYR02 Standards
ANSI C119.4|cULus RecognizedSKU #2339132Part Number #UYR02UNSPSC39121449UPC00783786756032
