WAGO 2001-1411/1000-411 Diode terminal block
Part Number # 2001-1411/1000-411
SKU # 2258070
Wago 2001-1411/1000-411 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2001-1411/1000-411 |
| SKU #: | 2258070 |
| Amperage Rating: | 0.5 A |
| Dimensions: | 2.752 in H x 0.165 in W x 1.295 in D |
| Number of Poles: | 1 |
| Temperature Rating (Degrees F): | -35 to 85 deg C |
| Type: | Operating Tool |
| Wire Size: | 22 to 14 AWG |
| Actuation type: | Push-in || Operating tool |
| Approvals per: | UL 1059 |
| Color: | Gray |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Push-In |
| Country of origin: | CN |
| Depth: | 69.9 mm / 2.752 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Nominal cross-section: | 1.5 mm² |
| Rated current: | 0.5 A |
| Solid conductor: | 0.25 … 2.5 mm² / 22 … 14 AWG |
| Total number of connection points: | 4 |
| Weight: | 6.210 g |
| Width: | 4.2 mm / 0.165 inch |
| Wiring type: | Front-entry wiring |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04045454537616 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
WAGO 2001-1411/1000-411 Diode terminal block
Brand: Wago
Part Number: 2001-1411/1000-411
Additional Description: WAGO-2001-1411/1000-411 COMPONENT TERMINAL BLOCK; 4-CONDUCTOR; WITH DIODE 1N4007; ANODE, RIGHT SIDE; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; 1.5 MM; PUSH-IN CAGE CLAMP; 1,50 MM; GRAY 51190178 4-CONDUCTOR; WITH DIODE 1N4007; X 15 AND 35 X 7.5; 1.5 MM ; PUSH-IN CAGE CLAMP ; 1,50 MM ; GRAY 60309839 (OLD # 51190178)
Catalog Description: Component terminal block; 4-conductor; with diode 1N4007; anode, right side; for DIN-rail 35 x 15 and 35 x 7.5; 1.5 mm²; Push-in CAGE CLAMP®; 1,50 mm²; gray
2001-1411/1000-411 Standards
UL 1059|RoHS CompliantSKU #2258070Part Number #2001-1411/1000-411UNSPSC39121410UPC04045454537616
