Part Number # 2004-1408
SKU # 2307077
Image Disclaimers Message
2004-1408
WAGO 2004-1408 Shield terminal block
Part Number # 2004-1408
SKU # 2307077
$8.34 / Each
Typical price:$9.04 / Each
Wago 2004-1408 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2004-1408 |
| SKU #: | 2307077 |
| Dimensions: | 3.098 in H x 0.244 in W x 1.295 in D |
| Number of Poles: | 1 |
| Type: | Operating Tool |
| Wire Size: | 20 to 10 AWG |
| Actuation type: | Push-in || Operating tool |
| Color: | White |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Clamp |
| Country of origin: | DE |
| Depth: | 78.7 mm / 3.098 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Nominal cross-section: | 4 mm² |
| Solid conductor: | 0.5 … 6 mm² / 20 … 10 AWG |
| Total number of connection points: | 4 |
| Weight: | 15.888 g |
| Width: | 6.2 mm / 0.244 inch |
| Wiring type: | Front-entry wiring |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04045454719500 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$8.34 / Each
Typical price:$9.04 / Each
Quantity:
WAGO 2004-1408 Shield terminal block
Brand: Wago
Part Number: 2004-1408
Additional Description: WAGO-2004-1408 4-CONDUCTOR SHIELD TERMINAL BLOCK; 4 MM; SIDE AND CENTER MARKING; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; PUSH-IN CAGE CLAMP; 4,00 MM; WHITE 20041408 4 MM ; SIDE AND CENTER MARKING; FOR PUSH-IN CAGE CLAMP ; 4,00 MM ; WHITE 20041408
Catalog Description: 4-conductor shield terminal block; 4 mm²; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP®; 4,00 mm²; white
2004-1408 Standards
IEC/EN 60947-7-2|RoHS CompliantSKU #2307077Part Number #2004-1408UNSPSC39121410UPC04045454719500
