WAGO 2091-1634/024-000 Panel feedthrough male connector

Name: WAGO 2091-1634/024-000 Panel feedthrough male connector
Brand: Wago
SKU: 2371900
Price: 2.3815 USD
Availability: OutOfStock

Part Number # 2091-1634/024-000

SKU # 2371900

$2.38 / Each

Typical price:$2.58 / Each

Wago 2091-1634/024-000 Key Features

Brand:	Wago
Part Number # :	2091-1634/024-000
SKU #:	2371900
Amperage Rating:	10 A
Dimensions:	0.488 in H x 1.102 in W x 1.142 in D
Number of Positions:	4
Temperature Rating (Degrees F):	-35 to 60 deg C
Type:	Pre-Assembled
Approvals per:	CSA, UL 1059
Color:	Light gray
Connector (connection type):	For pluggable connector
Contact material:	Electrolytic copper (ECu)
Country of origin:	DE
Depth:	29 mm / 1.142 inch
Height:	12.4 mm / 0.488 inch
Insulation material:	Polyphthalamide (PPA GF)
Material:	Polyphthalamide
Mounting type:	Mounting flange \|\| Feed-through mounting \|\| Panel mounting, Panel Feed Through
Number of connection types:	1
Rated current:	0.416666666666667
Weight:	2.500 g
Width:	28 mm / 1.102 inch
Manufacturer Name:	WAGO Corporation
UNSPSC:	39121459
UPC:	04050821161868

Buy Now Pay Later

Get 30 days to pay with Net 30 Terms. Apply Now.

$2.38 / Each

Typical price:$2.58 / Each

Quantity:

WAGO 2091-1634/024-000 Panel feedthrough male connector

Brand: Wago

Part Number: 2091-1634/024-000

Additional Description: WAGO-2091-1634/024-000 PANEL FEEDTHROUGH MALE CONNECTOR; CLAMPING COLLAR; PIN SPACING 3.5 MM; 4-POLE; LIGHT GRAY 51235185

Catalog Description: Panel feedthrough male connector; clamping collar; 1.5 mm²; 4-pole; Pin spacing 3.5 mm; light gray

Suitable for panel mounting

Male connectors for screw mounting in device or enclosure panels
Internal plug-in connection to female headers with solder pins or female connectors with conductor terminations
Also available with pre-assembled female connectors on both sides

UL 1059|IEC/EN 60664-1|RoHS Compliant

SKU #2371900

Part Number #2091-1634/024-000

UNSPSC39121459

UPC04050821161868
