2204-1407
WAGO 2204-1407 TOPJOB S ground terminal block with Push-buttons
Part Number # 2204-1407
SKU # 2362629
$8.95 / Each
Typical price:$9.70 / Each
Wago 2204-1407 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2204-1407 |
| SKU #: | 2362629 |
| Dimensions: | 3.098 in H x 0.244 in W x 1.295 in D |
| Number of Poles: | 1 |
| Type: | Operating Tool |
| Wire Size: | 20 to 10 AWG |
| Actuation type: | Push-in || Push-button || Operating tool |
| Color: | Green-yellow, Green/Yellow |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Push-In |
| Country of origin: | DE |
| Depth: | 78.7 mm / 3.098 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Nominal cross-section: | 4 mm² |
| Solid conductor: | 0.5 … 6 mm² / 20 … 10 AWG |
| Total number of connection points: | 4 |
| Weight: | 16.084 g |
| Width: | 6.2 mm / 0.244 inch |
| Wiring type: | Front-entry wiring |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04055143711333 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$8.95 / Each
Typical price:$9.70 / Each
Quantity:
- WAGO, 2204-1407, Ground Terminal Block, Operating Tool, 1 Pole, 20 to 10 AWG Wire, 0.43 to 0.51 in Wire Strip Length, DIN Rail Mounting, Push-In Connection, Polyamide, Green/Yellow, 3.098 in H x 0.244 in W x 1.295 in D Dimensions
2204-1407 Standards
IEC/EN 60947-7-2|RoHS CompliantSKU #2362629Part Number #2204-1407UNSPSC39121410UPC04055143711333
