Part Number # 2210-1204
SKU # 2428673
2210-1204
WAGO 2210-1204 Terminal Blocks
Part Number # 2210-1204
SKU # 2428673
Wago 2210-1204 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2210-1204 |
| SKU #: | 2428673 |
| Amperage Rating: | 57 A |
| Dimensions: | 2.661 in H x 0.394 in W x 1.713 in D |
| Number of Poles: | 1 |
| Type: | Operating Tool |
| Wire Size: | 20 to 6 AWG |
| Connection type: | Clamp |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04055143736077 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
WAGO 2210-1204 Terminal Blocks
Brand: Wago
Part Number: 2210-1204
Additional Description: WAGO-2210-1204 2-CONDUCTOR THROUGH TERMINAL BLOCK; WITH PUSH-BUTTON; 10 MM ; WITH TEST PORT; SUITABLE FOR EX I APPLICATIONS; SIDE AND CENTER MARKING; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; PUSH-IN CAGE CLAMP ; 10,00 MM ; BLUE 60365989
Catalog Description: 2-conductor through terminal block; with push-button; 10 mm²; with test port; suitable for Ex i applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP®; 10,00 mm²; blue
2210-1204 Application
Suitable for Ex i applications2210-1204 Standards
CSA 22.2 No 158|ATEX: PTB 18 ATEX 1008 U / IECEx: PTB 18.0015U (Ex eb IIC Gb)|RoHS CompliantSKU #2428673Part Number #2210-1204UNSPSC39121410UPC04055143736077
Image provided may only be a representation of final product and may include optional equipment
