Part Number # 2252-301
SKU # 2419803
Brand: Wago
2252-301
WAGO 2252-301 Terminal Blocks
Part Number # 2252-301
SKU # 2419803
$1.76 / Each
Typical price:$1.91 / Each
Wago 2252-301 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2252-301 |
| SKU #: | 2419803 |
| Amperage Rating: | 24 A |
| Dimensions: | 0.205 in W x 1.398 in D |
| Number of Poles: | 1 |
| Temperature Rating (Degrees F): | -35 to 85 deg C |
| Type: | 2-Conductor |
| Wire Size: | 22 to 12 AWG |
| Material: | Polyamide |
| Mounting type: | Flange, Surface |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04066966147032 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1.76 / Each
Typical price:$1.91 / Each
Quantity:
WAGO 2252-301 Terminal Blocks
Brand: Wago
Part Number: 2252-301
Additional Description: WAGO-2252-301 2-CONDUCTOR MINIATURE THROUGH TB 60488712
Catalog Description: 2-conductor miniature through terminal block; with push-button; 2.5 mm²; End terminal block with mounting flange; side and center marking; with test port; Push-in CAGE CLAMP®; 2,50 mm²; gray
2252-301 Standards
CSA 22.2 No 158|ATEX: PTB 20 ATEX 1013 U / IECEx: PTB 20.0029U (Ex eb IIC Gb)|RoHS CompliantSKU #2419803Part Number #2252-301UNSPSC39121410UPC04066966147032
Image provided may only be a representation of final product and may include optional equipment
