Part Number # 233-406
SKU # 2359238
Image Disclaimers Message
Brand: Wago
233-406
WAGO 233-406 PCB terminal block
Part Number # 233-406
SKU # 2359238
$188.68 / 70Each
Typical price:$204.40 / Each
Wago 233-406 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 233-406 |
| SKU #: | 2359238 |
| Amperage Rating: | 6 A |
| Dimensions: | 0.618 in H x 0.691 in W x 0.476 in D |
| Number of Poles: | 6 |
| Spacing: | 0.1 in |
| Type: | Operating Tool |
| Wire Size: | 28 to 20 AWG |
| Actuation type: | Operating tool |
| Approvals per: | CSA, UL 1059 |
| Color: | Orange |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Contact material: | Electrolytic copper (ECu) |
| Country of origin: | CH |
| Depth: | 12.1 mm / 0.476 inch |
| Height: | 15.7 mm / 0.618 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Number of connection types: | 1 |
| Rated current: | 0.25 |
| Solid conductor: | 0.08 … 0.5 mm² / 28 … 20 AWG |
| Total number of connection points: | 6 |
| Weight: | 2.156 g |
| Width: | 17.54 mm / 0.691 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121459 |
| UPC: | 04045454049973 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$188.68 / 70Each
Typical price:$204.40 / Each
Quantity:
WAGO 233-406 PCB terminal block
Brand: Wago
Part Number: 233-406
Additional Description: WAGO-233-406 PCB TERMINAL BLOCK; 0.5 MM ; PIN SPACING 2.54 MM; 6-POLE; CAGE CLAMP ; 0,50 MM ; ORANGE 51158982
Catalog Description: PCB terminal block; 0.5 mm²; Pin spacing 2.54 mm; 6-pole; CAGE CLAMP®; 0,50 mm²; orange
233-406 Item Features
- Compact terminal strips with CAGE CLAMP connection and screwdriver actuation parallel or perpendicular to conductor entry
- Double solder pins for high mechanical stability
- Custom color combinations
233-406 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2359238Part Number #233-406UNSPSC39121459UPC04045454049973
