Part Number # 253-106
SKU # 2296859
Image Disclaimers Message
Brand: Wago
253-106
WAGO 253-106 2-conductor PCB terminal block
Part Number # 253-106
SKU # 2296859
$129.15 / 35Each
Typical price:$140.00 / Each
Wago 253-106 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 253-106 |
| SKU #: | 2296859 |
| Amperage Rating: | 17.5 A |
| Dimensions: | 0.654 in H x 1.26 in W x 0.504 in D |
| Number of Poles: | 6 |
| Spacing: | 0.197 in |
| Type: | Operating Tool |
| Wire Size: | 20 to 16 AWG |
| Actuation type: | Operating tool |
| Approvals per: | CSA, UL 1059 |
| Color: | Gray |
| Connection technology: | PUSH WIRE® |
| Contact material: | Electrolytic copper (ECu) |
| Country of origin: | CN |
| Depth: | 12.8 mm / 0.504 inch |
| Height: | 16.6 mm / 0.654 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Number of connection points: | 1 |
| Number of connection points (connection type): | 1 |
| Number of connection types: | 2 |
| Rated current: | 17.5 A |
| Solid conductor: | 0.5 … 1.5 mm² / 20 … 16 AWG |
| Total number of connection points: | 12 |
| Weight: | 5.374 g |
| Width: | 32 mm / 1.26 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04044918689366 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$129.15 / 35Each
Typical price:$140.00 / Each
Quantity:
WAGO 253-106 2-conductor PCB terminal block
Brand: Wago
Part Number: 253-106
Additional Description: WAGO-253-106 2-CONDUCTOR PCB TERMINAL BLOCK; 1.5 MM; PIN SPACING 5 MM; 6-POLE; PUSH WIRE; 1,50 MM; GRAY 51143074 MM ; PIN SPACING 5 MM; 6-POLE; PUSH WIRE ; 1,50 MM ; GRAY 51143074
Catalog Description: 2-conductor PCB terminal block; 1.5 mm²; Pin spacing 5 mm; 6-pole; PUSH WIRE®; 1,50 mm²; gray
253-106 Item Features
- PCB terminal strips with screwdriver-actuated PUSH WIRE termination
- Double-conductor connection provides top-entry (vertical) and/or side-entry (horizontal) wiring
- Push-in termination of solid conductors
- Double entries for power supply and potential distribution
253-106 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2296859Part Number #253-106UNSPSC39121410UPC04044918689366
