Brand: Wago
255-412
WAGO 255-412 PCB terminal block
Part Number # 255-412
SKU # 2246631
$112.05 / 15Each
Typical price:$121.35 / Each
Wago 255-412 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 255-412 |
| SKU #: | 2246631 |
| Amperage Rating: | 24 A |
| Dimensions: | 0.717 in H x 2.476 in W x 0.72 in D |
| Number of Poles: | 12 |
| Spacing: | 0.2 in |
| Type: | Push Button |
| Wire Size: | 28 to 12 AWG |
| Actuation type: | Push-button |
| Approvals per: | CSA, UL 1059 |
| Color: | Gray |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Contact material: | Electrolytic copper (ECu) |
| Country of origin: | CH |
| Depth: | 18.3 mm / 0.72 inch |
| Height: | 18.2 mm / 0.717 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Number of connection types: | 1 |
| Rated current: | 24 A |
| Solid conductor: | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Total number of connection points: | 12 |
| Weight: | 14.384 g |
| Width: | 62.9 mm / 2.476 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04044918660099 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$112.05 / 15Each
Typical price:$121.35 / Each
Quantity:
WAGO 255-412 PCB terminal block
Brand: Wago
Part Number: 255-412
Additional Description: WAGO-255-412 PCB TERMINAL BLOCK; PUSH-BUTTON; 2.5 MM; PIN SPACING 5/5.08 MM; 12-POLE; CAGE CLAMP; COMMONING OPTION; 2,50 MM; GRAY 51141324 2.5 MM ; PIN SPACING 5/5.08 MM; 12-POLE; CAGE CLAMP ; COMMONING OPTION; 2,50 MM ; GRAY 51141324
Catalog Description: PCB terminal block; push-button; 2.5 mm²; Pin spacing 5/5.08 mm; 12-pole; CAGE CLAMP®; commoning option; 2,50 mm²; gray
255-412 Application
Ideal for in-the-field wiring thanks to simplified push-button actuation255-412 Item Features
- PCB terminal blocks with push-buttons and CAGE CLAMP connection
- Set to metric or inch pin spacing by compressing PCB terminal strips or pulling them apart
- Convenient, tool-free operation
255-412 Standards
CSA|IEC/EN 60664-1|RoHS Compliant|Ex approvalSKU #2246631Part Number #255-412UNSPSC39121410UPC04044918660099
