Part Number # 2604-3106
SKU # 2356856
Image Disclaimers Message
Brand: Wago
2604-3106
WAGO 2604-3106 PCB terminal block
Part Number # 2604-3106
SKU # 2356856
$5.82 / Each
Typical price:$6.30 / Each
Wago 2604-3106 Key Features
Brand: | Wago |
---|---|
Part Number # : | 2604-3106 |
SKU #: | 2356856 |
Amperage Rating: | 32 A |
Dimensions: | 0.996 in H x 1.276 in W x 0.657 in D |
Number of Poles: | 6 |
Spacing: | 0.197 in |
Type: | Lever |
Wire Size: | 24 to 12 AWG |
Actuation type: | Lever |
Approvals per: | CSA, UL 1059 |
Color: | Gray |
Connection technology: | Push-in CAGE CLAMP® |
Connection type: | Push-In |
Contact material: | Electrolytic copper (ECu) |
Country of origin: | DE |
Depth: | 16.7 mm / 0.657 inch |
Height: | 25.3 mm / 0.996 inch |
Insulation material: | Polyamide (PA66) |
Material: | Polyamide |
Number of connection types: | 1 |
Rated current: | 32 A |
Solid conductor: | 0.2 … 4 mm² / 24 … 12 AWG |
Total number of connection points: | 6 |
Weight: | 10.032 g |
Width: | 32.4 mm / 1.276 inch |
Manufacturer Name: | WAGO Corporation |
UNSPSC: | 39121459 |
UPC: | 04055143564755 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$5.82 / Each
Typical price:$6.30 / Each
Quantity:
WAGO 2604-3106 PCB terminal block
Brand: Wago
Part Number: 2604-3106
Additional Description: WAGO-2604-3106 PCB TERMINAL BLOCK; LEVER; 4 MM; PIN SPACING 5 MM; 6-POLE; PUSH-IN CAGE CLAMP; 4,00 MM; GRAY 60325983 CAGE CLAMP ; 4,00 MM ; GRAY 60325983
Catalog Description: PCB terminal block; lever; 4 mm²; Pin spacing 5 mm; 6-pole; Push-in CAGE CLAMP®; 4,00 mm²; gray
2604-3106 Item Features
- Push-in termination of solid and ferruled conductors
- Intuitive and tool-free operation
- Several clamping units can be held open simultaneously, simplifying the connection of multi-core cables
- Testing can be performed both parallel and perpendicular to conductor entry
2604-3106 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2356856Part Number #2604-3106UNSPSC39121459UPC04055143564755
