Brand: Wago
WAGO 270-586 3-conductor sensor/actuator terminal block
Image Disclaimers Message
Brand: Wago
WAGO 270-586 3-conductor sensor/actuator terminal block
Brand: Wago
WAGO 270-586 3-conductor sensor/actuator terminal block
Part #:270-586
SKU #: 2264488
$61.90/10EA
Key Features
Part #:270-586
SKU #: 2264488
Brand: Wago
Actuation type: Operating tool
Color: Orange
Connection technology: CAGE CLAMP®
Country of origin: CN
Depth: 68 mm / 2.677 inch
$61.90/10EA
Specifications
Brand: Wago
Actuation type: Operating tool
Color: Orange
Connection technology: CAGE CLAMP®
Country of origin: CN
Depth: 68 mm / 2.677 inch
Mounting type: DIN-35 rail
Rated current: 18 A
Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
Total number of connection points: 4
Weight: 8.700 g
Width: 5 mm / 0.197 inch
Wiring type: Front-entry wiring
UNSPSC: 39121469
UPC: 04050821035299
WAGO 270-586 3-conductor sensor/actuator terminal block
Additional Description: WAGO-270-586 3-CONDUCTOR SENSOR/ACTUATOR TERMINAL BLOCK; WITH COLORED CONDUCTOR ENTRIES; 2.5 MM; CAGE CLAMP; 2,50 MM; ORANGE 51226844 CONDUCTOR ENTRIES; 2.5 MM ; CAGE CLAMP ; 2,50 MM ; ORANGE 51226844
Catalog Description: 3-conductor sensor/actuator terminal block; with colored conductor entries; 2.5 mm²; CAGE CLAMP®; 2,50 mm²; orange
