Part Number # 280-684
SKU # 292879
Image Disclaimers Message
Brand: Wago
280-684
WAGO 280-684 3-conductor through terminal block
Part Number # 280-684
SKU # 292879
$3.05 / Each
Typical price:$3.30 / Each
Wago 280-684 Key Features
Brand: | Wago |
---|---|
Part Number # : | 280-684 |
SKU #: | 292879 |
Amperage Rating: | 24 A |
Dimensions: | 2.52 in H x 0.197 in W x 1.102 in D |
Number of Poles: | 1 |
Type: | Operating Tool |
Wire Size: | 28 to 12 AWG |
Actuation type: | Operating tool |
Color: | Blue |
Connection technology: | CAGE CLAMP® |
Connection type: | Clamp |
Country of origin: | DE |
Depth: | 64 mm / 2.52 inch |
Insulation material: | Polyamide (PA66) |
Material: | Polyamide |
Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
Rated current: | 24 A |
Solid conductor: | 0.08 … 2.5 mm² / 28 … 12 AWG |
Total number of connection points: | 3 |
Weight: | 7.576 g |
Width: | 5 mm / 0.197 inch |
Wiring type: | Front-entry wiring |
Manufacturer Name: | WAGO Corporation |
UNSPSC: | 39121410 |
UPC: | 04044918391412 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$3.05 / Each
Typical price:$3.30 / Each
Quantity:
- WAGO, 280-684, Conductor Terminal Block, Operating Tool, 800 V, 24 A, 1 Pole, 28 to 12 AWG Wire, 0.31 to 0.35 in Wire Strip Length, DIN Rail Mounting, Clamp Connection, Polyamide, Blue, 2.52 in H x 0.197 in W x 1.102 in D Dimensions
280-684 Application
Suitable for Ex i applications280-684 Standards
CSA 22.2 No 158|IEC/EN 60947-7-1|RoHS CompliantSKU #292879Part Number #280-684UNSPSC39121410UPC04044918391412
