Part Number # 281-613/281-418
SKU # 2357643
Image Disclaimers Message
281-613/281-418
WAGO 281-613/281-418 2-conductor fuse terminal block
Part Number # 281-613/281-418
SKU # 2357643
Wago 281-613/281-418 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 281-613/281-418 |
| SKU #: | 2357643 |
| Amperage Rating: | 10 A |
| Dimensions: | 2.362 in H x 0.394 in W x 2.362 in D |
| Number of Poles: | 2 |
| Type: | Operating Tool |
| Wire Size: | 28 to 12 AWG |
| Actuation type: | Operating tool |
| Color: | Gray |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Country of origin: | DE |
| Depth: | 60 mm / 2.362 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Rated current: | 0.416666666666667 |
| Solid conductor: | 0.08 … 4 mm² / 28 … 12 AWG |
| Total number of connection points: | 2 |
| Weight: | 19.908 g |
| Width: | 10 mm / 0.394 inch |
| Wiring type: | Front-entry wiring |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04045454197032 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
WAGO 281-613/281-418 2-conductor fuse terminal block
Brand: Wago
Part Number: 281-613/281-418
Additional Description: WAGO-281-613/281-418 2-CONDUCTOR FUSE TERMINAL BLOCK; WITH PIVOTING FUSE HOLDER; FOR MINIATURE METRIC FUSE 1/4 X 1 MM; WITH BLOWN FUSE INDICATION BY NEON LAMP; 120 V; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; 4 MM ; CAGE CLAMP ; 4,00 MM ; GRAY 51168562
Catalog Description: 2-conductor fuse terminal block; with pivoting fuse holder; for miniature metric fuse 1/4 x 1 mm; with blown fuse indication by neon lamp; 120 V; for DIN-rail 35 x 15 and 35 x 7.5; 4 mm²; CAGE CLAMP®; 4,00 mm²; gray
281-613/281-418 Standards
IEC/EN 60947-7-3|RoHS CompliantSKU #2357643Part Number #281-613/281-418UNSPSC39121410UPC04045454197032
