Brand: Wago
WAGO 2857-534 JUMPFLEX signal conditioner
Image Disclaimers Message
Brand: Wago
WAGO 2857-534 JUMPFLEX signal conditioner
Brand: Wago
WAGO 2857-534 JUMPFLEX signal conditioner
Part #:2857-534
SKU #: 2308010
$400.72/EA
Key Features
Part #:2857-534
SKU #: 2308010
Brand: Wago
Connection technology: Push-in CAGE CLAMP®
Country of origin: DE
Depth: 110 mm / 4.331 inch
Hysteresis: Adjustable via DIP switch or software
Input signal type: TC sensors
$400.72/EA
Specifications
Brand: Wago
Connection technology: Push-in CAGE CLAMP®
Country of origin: DE
Depth: 110 mm / 4.331 inch
Hysteresis: Adjustable via DIP switch or software
Input signal type: TC sensors
Mounting type: DIN-35 rail
Number of changeover/switchover contacts: 1
Power consumption at nominal supply voltage: ≤ 40 mA (+ IDO)
Power supply type: 24 VDC
Sensor types (TC): Type J || Type K || Type E || Type N || Type R || Type S || Type T || Type B || Type C
Solid conductor: 0.2 … 2.5 mm² / 24 … 12 AWG
Standards/Specifications: EN 61010-1; EN 61373
Supply voltage range: ±30 %
WAGO Connector: picoMAX® 5.0
Weight: 105.800 g
Width: 12.5 mm / 0.492 inch
UNSPSC: 43232306
UPC: 04055143242318
WAGO 2857-534 JUMPFLEX signal conditioner
Additional Description: WAGO-2857-534 TVS TEMP-TC 1NO 60248676
Catalog Description: Threshold value switches; Thermocouples; 1 make contact; Digital output; Configuration via software; Supply voltage: 24 VDC; 12.5 mm module width
