Part Number # 289-576
SKU # 2198741
Wago 289-576 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 289-576 |
| SKU #: | 2198741 |
| Amperage Rating: | 2 A |
| Dimensions: | 3.346 in H x 1.693 in W x 1.339 in D |
| Number of Poles: | 15, 16 |
| Series: | 289 |
| Temperature Rating (Degrees F): | -20 to 50 deg C |
| Terminal Type: | Screw |
| Wire Size: | 28 to 12 AWG |
| Country of origin: | DE |
| Depth: | 85 mm / 3.346 inch |
| For mating connector: | With solder contact |
| Mounting type: | DIN Rail, DIN-35 rail |
| Operating voltage: | ≤ AC/DC 125 V |
| Performance level: | 2 / 200 mating cycles |
| Protection type: | IP20 |
| Rated voltage: | 125 V |
| Standards/Specifications: | EN 61010-2-201 |
| Strain relief: | UNC 4-40 stud bolt |
| Weight: | 58.775 g |
| Width: | 43 mm / 1.693 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 32151603 |
| UPC: | 04045454417925 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$90.96 / Each
Quantity:
WAGO 289-576 Interface module
Brand: Wago
Part Number: 289-576
Additional Description: WAGO-289-576 IM SUB-D F 51182384
Catalog Description: Interface module; with solder pin; Female connector; 15-pole; Mating connector with solder connection; Vertical mounting; PCB terminal blocks, double-row; in mounting carrier; with shield connection; 2,50 mm²
289-576 Standards
RoHS CompliantSKU #2198741Part Number #289-576UNSPSC32151603UPC04045454417925
Image provided may only be a representation of final product and may include optional equipment
