704-2054
WAGO 704-2054 Interface module for system wiring
Part Number # 704-2054
SKU # 2352308
$405.78 / Each
Wago 704-2054 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 704-2054 |
| SKU #: | 2352308 |
| Dimensions: | 3.346 in H x 3.346 in W x 2.48 in D |
| Number of Poles: | 20 |
| Temperature Rating (Degrees F): | -20 to 50 deg C |
| Type: | Male |
| Wire Size: | 28 to 12 AWG |
| Circuit type: | 3-wire connection |
| Country of origin: | FR |
| Depth: | 85 mm / 3.346 inch |
| Inputs/outputs: | 16-channel digital input or output |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Operating voltage range: | ±10 % |
| Rated voltage: | 50 V |
| Status indicator: | Green LED (channel) || Yellow LED (power supply) |
| Total current: | 0.0833333333333333 |
| Weight: | 143.000 g |
| Width: | 85 mm / 3.346 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04050821220602 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$405.78 / Each
Quantity:
- WAGO, 704-2054, Interface Module, Male, 24 V DC, 20 Pole, 28 to 12 AWG Wire, 0.20 to 0.24 in Wire Strip Length, DIN Rail Mounting, -20 to 50 deg C, 3.346 in H x 3.346 in W x 2.48 in D Dimensions
704-2054 Standards
DIN 41651|RoHS CompliantSKU #2352308Part Number #704-2054UNSPSC43232306UPC04050821220602
