Brand: Wago
704-5004
WAGO 704-5004 Interface module for system wiring
Part Number # 704-5004
SKU # 2296204
$1168.46 / Each
Wago 704-5004 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 704-5004 |
| SKU #: | 2296204 |
| Dimensions: | 4.134 in H x 7.087 in W x 1.969 in D |
| Number of Poles: | 20 |
| Temperature Rating (Degrees F): | -25 to 50 deg C |
| Type: | Double-Deck |
| Wire Size: | 28 to 12 AWG |
| Country of origin: | FR |
| Depth: | 105 mm / 4.134 inch |
| Inputs/outputs: | 16-channel relay output |
| Mechanical life: | 30 x 106 switching operations |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Number of changeover/switchover contacts: | 1 |
| Operating voltage range: | ±10 % |
| Rated voltage: | 50 V |
| Status indicator: | Green LED (channel) || Yellow LED (power supply) |
| Weight: | 550.000 g |
| Width: | 180 mm / 7.087 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04045454980108 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1168.46 / Each
Quantity:
- WAGO, 704-5004, Interface Module, Double-Deck, 24 V DC, 20 Pole, 28 to 12 AWG Wire, 0.20 to 0.24 in Wire Strip Length, DIN Rail Mounting, -25 to 50 deg C, 4.134 in H x 7.087 in W x 1.969 in D Dimensions
704-5004 Standards
DIN 41651|RoHS CompliantSKU #2296204Part Number #704-5004UNSPSC43232306UPC04045454980108
