Part Number # 704-5074
SKU # 2352310
704-5074
WAGO 704-5074 Interface module for system wiring
Part Number # 704-5074
SKU # 2352310
Wago 704-5074 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 704-5074 |
| SKU #: | 2352310 |
| Dimensions: | 4.134 in H x 9.449 in W x 2.165 in D |
| Temperature Rating (Degrees F): | -25 to 50 deg C |
| Wire Size: | 28 to 12 AWG |
| Inputs/outputs: | 16-channel relay output |
| Mechanical life: | 30 x 106 switching operations |
| Number of make/switch-on contacts: | 1 |
| Operating voltage range: | ±10 % |
| Rated voltage: | 50 V |
| Status indicator: | Green LED (channel) || Yellow LED (power supply) |
| Weight: | 785.000 g |
| Width: | 240 mm / 9.449 inch |
| UNSPSC: | 43232306 |
| UPC: | 04045454980207 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
WAGO 704-5074 Interface module for system wiring
Brand: Wago
Part Number: 704-5074
Additional Description: WAGO-704-5074 INTERFACE MODULE FOR SYSTEM WIRING; PLUGGABLE CONNECTOR PER DIN 41651; MALE CONNECTOR; 20-POLE; 16-CHANNEL RELAY OUTPUT; 1 MAKE CONTACT; WITH DISCONNECT TERMINAL BLOCK AND FUSE; IN MOUNTING CARRIER; 2,50 MM 07045074
Catalog Description: Interface module for system wiring; Pluggable connector per DIN 41651; Male connector; 20-pole; 16-channel relay output; 1 make contact; with disconnect terminal block and fuse; in mounting carrier; 2,50 mm²
704-5074 Standards
DIN 41651|RoHS CompliantSKU #2352310Part Number #704-5074UNSPSC43232306UPC04045454980207
Image provided may only be a representation of final product and may include optional equipment
