Part Number # 713-1108/107-047
SKU # 2347065
Image Disclaimers Message
713-1108/107-047
WAGO 713-1108/107-047 1-conductor female connector, 2-row
Part Number # 713-1108/107-047
SKU # 2347065
$17.75 / Each
Typical price:$19.23 / Each
Wago 713-1108/107-047 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 713-1108/107-047 |
| SKU #: | 2347065 |
| Amperage Rating: | 10 A |
| Dimensions: | 0.74 in H x 1.5 in W x 0.63 in D |
| Number of Poles: | 16 |
| Temperature Rating (Degrees F): | -35 to 60 deg C |
| Type: | Operating Tool |
| Wire Size: | 28 to 16 AWG |
| Actuation type: | Operating tool |
| Approvals per: | CSA, UL 1059 |
| Color: | Black |
| Conductor entry direction to mating direction: | 0 ° |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Connector (connection type): | For conductor |
| Contact material: | Copper alloy |
| Country of origin: | PL |
| Depth: | 16 mm / 0.63 inch |
| Height: | 18.8 mm / 0.74 inch |
| Insulation material: | Glass fiber-reinforced polyamide (PA66 GF) |
| Material: | Polyamide |
| Number of connection types: | 1 |
| Rated current: | 0.416666666666667 |
| Solid conductor: | 0.08 … 1.5 mm² / 28 … 16 AWG |
| Total number of connection points: | 16 |
| Weight: | 8.850 g |
| Width: | 38.1 mm / 1.5 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04050821177708 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$17.75 / Each
Typical price:$19.23 / Each
Quantity:
WAGO 713-1108/107-047 1-conductor female connector, 2-row
Brand: Wago
Part Number: 713-1108/107-047
Additional Description: WAGO-713-1108/107-047 1-CONDUCTOR FEMALE PLUG; 100% PROTECTED AGAINST MISMATING; SCREW FLANGE; DIRECT MARKING; 1.5 MM ; PIN SPACING 3.5 MM; 16-POLE; 1,50 MM ; BLACK 51236345
Catalog Description: 1-conductor female connector, 2-row; CAGE CLAMP®; 1.5 mm²; Pin spacing 3.5 mm; 16-pole; 100% protected against mismating; Screw flange; direct marking; 1,50 mm²; black
713-1108/107-047 Item Features
- Universal connection for all conductor types
- Unique, compact, double-row connector system for conductor cross-sections up to 1.5 mm^2
- High-density, wire-to-board connections in very confined spaces
- Centered strain relief plate anchors conductors, while acting as convenient connection and disconnection handle
- It also provides easy access to operating slots - even when wired
- Coding fingers provide 100 Percent protection against mismating
713-1108/107-047 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2347065Part Number #713-1108/107-047UNSPSC39121421UPC04050821177708
