Brand: Wago
WAGO 733-362 THT male header
Image Disclaimers Message
Brand: Wago
WAGO 733-362 THT male header
Brand: Wago
WAGO 733-362 THT male header
Part #:733-362
SKU #: 2277612
$0.64/EA
Key Features
Part #:733-362
SKU #: 2277612
Brand: Wago
Amperage Rating: 6 A
Dimensions: 0.453 in H x 0.295 in W x 0.35 in D
Finish: Tin Plated
Number of Positions: 2
Series: 733
$0.64/EA
- 100% protected against mismating
- only mating halves with the same pole number can be connected
- Coding option available
Specifications
Brand: Wago
Amperage Rating: 6 A
Dimensions: 0.453 in H x 0.295 in W x 0.35 in D
Finish: Tin Plated
Number of Positions: 2
Series: 733
Temperature Rating (Degrees F): 60 to 100 deg C
Terminal Type: Solder
Type: Angled
Voltage Rating: 320 V
Approvals per: CSA, UL 1059
Color: Light gray
Connector (connection type): For PCB
Contact material: Electrolytic copper (ECu)
Contact type (pluggable connector): Male connector/plug
Country of origin: DE
Depth: 8.9 mm / 0.35 inch
Height: 11.5 mm / 0.453 inch
Insulation material: Polyamide (PA66)
Material: Electrolytic Copper/Polyamide 6.6
Mounting type: PCB
Number of connection types: 1
Rated current: 0.25
Weight: 0.392 g
Width: 7.5 mm / 0.295 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 39121421
UPC: 04044918974325
Item FeaturesConnectors
Item Features
Item FeaturesRoHS Compliant|UL94|DIN EN 61984
