Part Number # 735-304
SKU # 2297692
Image Disclaimers Message
Brand: Wago
735-304
WAGO 735-304 PCB terminal block
Part Number # 735-304
SKU # 2297692
$97.20 / 60Each
Typical price:$105.00 / Each
Wago 735-304 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 735-304 |
| SKU #: | 2297692 |
| Amperage Rating: | 10 A |
| Dimensions: | 0.764 in H x 0.787 in W x 0.425 in D |
| Number of Poles: | 4 |
| Spacing: | 0.197 in |
| Type: | Push Button |
| Wire Size: | 20 to 16 AWG |
| Actuation type: | Push-button |
| Approvals per: | CSA, UL 1059 |
| Color: | Gray |
| Connection technology: | PUSH WIRE® |
| Contact material: | Electrolytic copper (ECu) |
| Country of origin: | CH |
| Depth: | 10.8 mm / 0.425 inch |
| Height: | 19.4 mm / 0.764 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Number of connection types: | 1 |
| Rated current: | 0.416666666666667 |
| Solid conductor: | 0.5 … 1.5 mm² / 20 … 16 AWG |
| Total number of connection points: | 4 |
| Weight: | 3.357 g |
| Width: | 20 mm / 0.787 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04044918793070 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$97.20 / 60Each
Typical price:$105.00 / Each
Quantity:
WAGO 735-304 PCB terminal block
Brand: Wago
Part Number: 735-304
Additional Description: WAGO-735-304 PCB TERMINAL BLOCK; PUSH-BUTTON; 1.5 MM ; PIN SPACING 5 MM; 4-POLE; PUSH WIRE ; 1,50 MM ; GRAY 51146371
Catalog Description: PCB terminal block; push-button; 1.5 mm²; Pin spacing 5 mm; 4-pole; PUSH WIRE®; 1,50 mm²; gray
735-304 Item Features
- Compact PCB terminal blocks with push-buttons and PUSH WIRE connection
- Top-of-unit, push-button actuation and conductor termination save space on the PCB
- Push-in termination of solid conductors
- Terminal blocks can be arranged side-by-side without loss of poles
735-304 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2297692Part Number #735-304UNSPSC39121421UPC04044918793070
