736-406
WAGO 736-406 Double-deck PCB terminal block
Part Number # 736-406
SKU # 2325238
$5.74 / Each
Typical price:$6.22 / Each
Wago 736-406 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 736-406 |
| SKU #: | 2325238 |
| Amperage Rating: | 21 A |
| Dimensions: | 1.201 in H x 1.239 in W x 0.827 in D |
| Number of Poles: | 12 |
| Spacing: | 0.2 in |
| Type: | Operating Tool |
| Wire Size: | 28 to 12 AWG |
| Actuation type: | Operating tool |
| Approvals per: | CSA, UL 1059 |
| Color: | Orange |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Contact material: | Electrolytic copper (ECu) |
| Country of origin: | PL |
| Depth: | 21 mm / 0.827 inch |
| Height: | 30.5 mm / 1.201 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Number of connection types: | 1 |
| Rated current: | 21 A |
| Solid conductor: | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Total number of connection points: | 12 |
| Weight: | 14.113 g |
| Width: | 31.48 mm / 1.239 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04044918915762 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$5.74 / Each
Typical price:$6.22 / Each
Quantity:
WAGO 736-406 Double-deck PCB terminal block
Brand: Wago
Part Number: 736-406
Additional Description: WAGO-736-406 DOUBLE-DECK PCB TERMINAL BLOCK; 2.5 MM ; PIN SPACING 5.08 MM; 2 X 6-POLE; CAGE CLAMP ; 2,50 MM ; ORANGE 51151935
Catalog Description: Double-deck PCB terminal block; 2.5 mm²; Pin spacing 5.08 mm; 12-pole; CAGE CLAMP®; 2,50 mm²; orange
736-406 Item Features
- PCB terminal strips with screwdriver-actuated CAGE CLAMP connection
- High-density, double-deck design for space-efficient wiring of multiple conductors in confined areas
- Custom marking for all termination levels
736-406 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2325238Part Number #736-406UNSPSC39121421UPC04044918915762
