WAGO 739-310 PCB terminal block
Part Number # 739-310
SKU # 2199249
$123.00 / 30Each
Typical price:$133.20 / Each
Wago 739-310 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 739-310 |
| SKU #: | 2199249 |
| Amperage Rating: | 17.5 A |
| Dimensions: | 0.618 in H x 1.437 in W x 0.528 in D |
| Number of Poles: | 10 |
| Spacing: | 0.138 in |
| Type: | Operating Tool |
| Wire Size: | 28 to 14 AWG |
| Actuation type: | Operating tool |
| Approvals per: | CSA, UL 1059 |
| Color: | Gray |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Contact material: | Electrolytic copper (ECu) |
| Country of origin: | PL |
| Depth: | 13.4 mm / 0.528 inch |
| Height: | 15.7 mm / 0.618 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Number of connection types: | 1 |
| Rated current: | 17.5 A |
| Solid conductor: | 0.08 … 1.5 mm² / 28 … 14 AWG |
| Total number of connection points: | 10 |
| Weight: | 6.518 g |
| Width: | 36.5 mm / 1.437 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04044918301442 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$123.00 / 30Each
Typical price:$133.20 / Each
Quantity:
WAGO 739-310 PCB terminal block
Brand: Wago
Part Number: 739-310
Additional Description: WAGO-739-310 PCB TERMINAL BLOCK; 1.5 MM ; PIN SPACING 3.5 MM; 10-POLE; CAGE CLAMP ; 1,50 MM ; GRAY 51113921
Catalog Description: PCB terminal block; 1.5 mm²; Pin spacing 3.5 mm; 10-pole; CAGE CLAMP®; 1,50 mm²; gray
739-310 Item Features
- PCB terminal strips with screwdriver-actuated CAGE CLAMP connection
- Vertical conductor entry and operating direction for space-saving positioning/grouping
739-310 Standards
UL 1059|IEC/EN 60664-1|RoHS CompliantSKU #2199249Part Number #739-310UNSPSC39121421UPC04044918301442
