Part Number # 745-354
SKU # 2399980
Image Disclaimers Message
745-354
WAGO 745-354 Electrical Connector Assembly
Part Number # 745-354
SKU # 2399980
$4.50 / Each
Typical price:$4.87 / Each
Wago 745-354 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 745-354 |
| SKU #: | 2399980 |
| Amperage Rating: | 41 A |
| Dimensions: | 1.083 in H x 1.539 in W x 1.146 in D |
| Number of Poles: | 4 |
| Spacing: | 0.39 in |
| Type: | Operating Tool |
| Wire Size: | 24 to 10 AWG |
| Color: | Gray |
| Connection type: | Clamp |
| Material: | Polyamide |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04044918302432 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$4.50 / Each
Typical price:$4.87 / Each
Quantity:
WAGO 745-354 Electrical Connector Assembly
Brand: Wago
Part Number: 745-354
Additional Description: WAGO-745-354 PCB TERMINAL BLOCK; 6 MM ; PIN 51114018 COMMONING OPTION; 6,00 MM ; GRAY
Catalog Description: PCB terminal block; 6 mm²; Pin spacing 10 mm; 4-pole; CAGE CLAMP®; commoning option; 6,00 mm²; gray
745-354 Item Features
- PCB terminal strips with screwdriver-actuated CAGE CLAMP connection
- Common and distribute potentials via comb-style jumper bars
- Double solder pins for high mechanical stability
- Custom color combinations
- Integrated testing tap
- Marker slot for Mini-WSB markers
745-354 Standards
CSA|IEC/EN 60664-1|RoHS Compliant|Ex approvalSKU #2399980Part Number #745-354UNSPSC39121421UPC04044918302432
