Brand: Wago
WAGO 750-433 4-channel digital input
Image Disclaimers Message
Brand: Wago
WAGO 750-433 4-channel digital input
Brand: Wago
WAGO 750-433 4-channel digital input
Part #:750-433
SKU #: 2153973
$72.78/EA
Key Features
Part #:750-433
SKU #: 2153973
Brand: Wago
Color: Light gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 69.8 mm / 2.748 inch
Height: 100 mm / 3.937 inch
$72.78/EA
Specifications
Brand: Wago
Color: Light gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 69.8 mm / 2.748 inch
Height: 100 mm / 3.937 inch
Housing material: Polycarbonate, polyamide 6.6
Input data width (internal) (max.): 4 bit
Isolation: 500 V system/field
Mounting position: Horizontal (standing/lying); vertical
Mounting type: DIN-35 rail
Number of digital inputs: 4
Protection type: IP20
Sensor connection: 4 x (2-wire)
Signal type: Voltage
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Supply voltage (sensor): DC 24 V
Total number of channels (module): 4
Vibration resistance: 4g per IEC 60068-2-6
Weight: 48.000 g
Width: 12 mm / 0.472 inch
UNSPSC: 32151702
UPC: 04045454466183
WAGO 750-433 4-channel digital input
Additional Description: WAGO-750-433 (D) 4-CHANNEL DIGITAL INPUT; 24 VDC; 0.2 MS; 2-CONDUCTOR CONNECTION; LIGHT GRAY 51186007
Catalog Description: 4-channel digital input; 24 VDC; 0.2 ms; 2-conductor connection
