Brand: Wago
WAGO 750-468/040-000 4-channel analog input
Image Disclaimers Message
Brand: Wago
WAGO 750-468/040-000 4-channel analog input
Brand: Wago
WAGO 750-468/040-000 4-channel analog input
Part #:750-468/040-000
SKU #: 2292458
$620.58/EA
Key Features
Part #:750-468/040-000
SKU #: 2292458
Brand: Wago
Color: Dark gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 67.8 mm / 2.669 inch
Dielectric strength: 510 VAC/775 VDC; per EN 60870-2-1
$620.58/EA
Specifications
Brand: Wago
Color: Dark gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 67.8 mm / 2.669 inch
Dielectric strength: 510 VAC/775 VDC; per EN 60870-2-1
Height: 100 mm / 3.937 inch
Housing material: Polycarbonate, polyamide 6.6
Mounting position: Horizontal (standing/lying); vertical
Mounting type: DIN-35 rail
Number of analog inputs: 4
Protection type: IP20
Sensor connection: 4 x (2-wire)
Signal characteristic: Single-ended
Signal type: Voltage
Solid conductor: 0.25 … 2.5 mm² / 24 … 14 AWG
Total number of channels (module): 4
Vibration resistance: Per IEC 60068-2-6 (acceleration: 5g), EN 60870-2-2, IEC 60721-3-1, -3, EN 50155; EN 61373
Weight: 50.000 g
Width: 12 mm / 0.472 inch
UNSPSC: 32151702
UPC: 04050821460268
WAGO 750-468/040-000 4-channel analog input
Additional Description: WAGO-750-468/040-000 4-CHANNEL ANALOG INPUT; 0 ... 10 VDC; SINGLE-ENDED; EXTREME; DARK GRAY 51259085
Catalog Description: 4-channel analog input; 0 ... 10 VDC; Single-ended; Extreme
