WAGO 750-469/040-000 2-channel analog input

Name: WAGO 750-469/040-000 2-channel analog input
Brand: Wago
SKU: 2357038
Price: 927.7292 USD
Availability: OutOfStock

Part Number # 750-469/040-000

SKU # 2357038

$927.73 / Each

Wago 750-469/040-000 Key Features

Brand:	Wago
Part Number # :	750-469/040-000
SKU #:	2357038
Dimensions:	3.93 in H x 0.47 in W x 2.66 in D
Enclosure Type:	IP20
Input Type:	Analog
Type:	2-Channel
Color:	Dark gray
Connection technology:	8 x CAGE CLAMP®
Country of origin:	DE
Depth:	67.8 mm / 2.669 inch
Dielectric strength:	510 VAC/775 VDC; per EN 60870-2-1
Height:	100 mm / 3.937 inch
Housing material:	Polycarbonate, polyamide 6.6
Material:	Polycarbonate/Polyamide 6.6
Mounting position:	Horizontal (standing/lying); vertical
Mounting type:	35 mm DIN Rail, DIN-35 rail
Number of analog inputs:	2
Protection type:	IP20
Sensor connection:	2 x (2-wire)
Sensor types:	Thermocouple K; Configurable: J, E, S, T, L, N, U, B, R; ±30 mV, ±60 mV, ±120 mV
Signal type:	Thermocouple \|\| Low voltages
Solid conductor:	0.25 … 2.5 mm² / 24 … 14 AWG
Temperature range:	Sensor-specific
Total number of channels (module):	2
Vibration resistance:	Per IEC 60068-2-6 (acceleration: 5g), EN 60870-2-2, IEC 60721-3-1, -3, EN 50155; EN 61373
Weight:	38.806 g
Width:	12 mm / 0.472 inch
Manufacturer Name:	WAGO Corporation
UNSPSC:	32151603
UPC:	04050821460336

Buy Now Pay Later

Get 30 days to pay with Net 30 Terms. Apply Now.

$927.73 / Each

Quantity:

WAGO 750-469/040-000 2-channel analog input

Brand: Wago

Part Number: 750-469/040-000

Additional Description: WAGO-750-469/040-000 2-CHANNEL ANALOG INPUT; THERMOCOUPLE; ADJUSTABLE; EXTREME; DARK GRAY 51259092 DARK GRAY 51259092

Catalog Description: 2-channel analog input; Thermocouple; Adjustable; Extreme

For marine applications

RoHS Compliant|CE|IP20

SKU #2357038

Part Number #750-469/040-000

UNSPSC32151603

UPC04050821460336
