Part Number # 750-563/040-000
SKU # 2292456
Image Disclaimers Message
750-563/040-000
WAGO 750-563/040-000 2-channel analog output
Part Number # 750-563/040-000
SKU # 2292456
$717.98 / Each
Wago 750-563/040-000 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 750-563/040-000 |
| SKU #: | 2292456 |
| Dimensions: | 3.93 in H x 0.47 in W x 2.74 in D |
| Enclosure Type: | IP20 |
| Type: | 2-Channel |
| Color: | Dark gray |
| Connection technology: | 8 x CAGE CLAMP® |
| Country of origin: | DE |
| Depth: | 67.8 mm / 2.669 inch |
| Dielectric strength: | 510 VAC/775 VDC; per EN 60870-2-1 |
| Height: | 100 mm / 3.937 inch |
| Housing material: | Polycarbonate, polyamide 6.6 |
| Material: | Polycarbonate/Polyamide 6.6 |
| Mounting position: | Horizontal (standing/lying); vertical |
| Mounting type: | 35 mm DIN Rail, DIN-35 rail |
| Number of analog outputs: | 2 |
| Output type: | Analog |
| Protection type: | IP20 |
| Signal type: | Electricity || Voltage |
| Solid conductor: | 0.25 … 2.5 mm² / 24 … 14 AWG |
| Total number of channels (module): | 2 |
| Vibration resistance: | Per IEC 60068-2-6 (acceleration: 5g), EN 60870-2-2, IEC 60721-3-1, -3, EN 50155; EN 61373 |
| Weight: | 51.000 g |
| Width: | 12 mm / 0.472 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 32151702 |
| UPC: | 04050821460367 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$717.98 / Each
Quantity:
- WAGO, 750-563/040-000, Analog Output, 2-Channel, Analog Output, IP20 Enclosure, 35 mm DIN Rail Mounting, Polycarbonate/Polyamide 6.6, Dark Gray, 3.93 in H x 0.47 in W x 2.74 in D Dimensions
750-563/040-000 Application
For marine applications750-563/040-000 Item Features
- An extended temperature range
- Greater immunity to impulse voltages and electromagnetic interference
- Higher vibration and shock resistance
750-563/040-000 Standards
RoHS Compliant|CE|IP20SKU #2292456Part Number #750-563/040-000UNSPSC32151702UPC04050821460367
