750-632
WAGO 750-632 Proportional valve module
Part Number # 750-632
SKU # 2311765
$564.82 / Each
Wago 750-632 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 750-632 |
| SKU #: | 2311765 |
| Color: | Light gray |
| Connection technology: | 16 x Push-in CAGE CLAMP® |
| Country of origin: | DE |
| Depth: | 69 mm / 2.717 inch |
| Height: | 100 mm / 3.937 inch |
| Housing material: | Polycarbonate, polyamide 6.6 |
| Isolation: | 500 V system/field |
| Load type: | Operating range: inductive (1 mH … 600 mH); Internal load resistance (> 8 Ohm) |
| Mounting position: | Horizontal (standing/lying); vertical |
| Mounting type: | DIN-35 rail |
| Number of digital inputs: | 2 |
| Number of outputs: | 2 bipolar outputs (A+, A- and B+, B-) |
| Output current: | 1-channel operation: 2 A; 2-channel operation: 1.6 A per channel |
| Output type: | H-bridge output with current-regulated PWM output (short-circuit-proof and thermal overload-proof for each channel) |
| Protection type: | IP20 |
| Solid conductor: | 0.08 … 1.5 mm² / 28 … 16 AWG |
| Vibration resistance: | 4g per IEC 60068-2-6 |
| Weight: | 54.400 g |
| Width: | 12 mm / 0.472 inch |
| UNSPSC: | 32151702 |
| UPC: | 04050821782346 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$564.82 / Each
Quantity:
WAGO 750-632 Proportional valve module
Brand: Wago
Part Number: 750-632
Additional Description: WAGO-750-632 PROPORTIONAL VALVE MODULE; LIGHT GRAY 7500632
Catalog Description: Proportional valve module
SKU #2311765Part Number #750-632UNSPSC32151702UPC04050821782346
