Brand: Wago
WAGO 750-650/003-000 RS-232 C Serial Interface
Image Disclaimers Message
Brand: Wago
WAGO 750-650/003-000 RS-232 C Serial Interface
Brand: Wago
WAGO 750-650/003-000 RS-232 C Serial Interface
Part #:750-650/003-000
SKU #: 2229180
$576.95/EA
Key Features
Part #:750-650/003-000
SKU #: 2229180
Brand: Wago
Baud rate: 1.2 kBd … 57.6 kBd (9600 baud (default setting))
Color: Light gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 69.8 mm / 2.748 inch
$576.95/EA
Specifications
Brand: Wago
Baud rate: 1.2 kBd … 57.6 kBd (9600 baud (default setting))
Color: Light gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 69.8 mm / 2.748 inch
Height: 100 mm / 3.937 inch
Housing material: Polycarbonate, polyamide 6.6
Isolation: 500 V system/field
Mounting position: Horizontal (standing/lying); vertical
Mounting type: DIN-35 rail
Number of data bits: 7/8, adjustable
Number of stop bits: 1/2, adjustable
Protection type: IP20
Signal type: RS-232
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Vibration resistance: 4g per IEC 60068-2-6
Weight: 48.095 g
Width: 12 mm / 0.472 inch
UNSPSC: 32151702
UPC: 04045454394271
WAGO 750-650/003-000 RS-232 C Serial Interface
Additional Description: WAGO-750-650/003-000 RS-232 C SERIAL INTERFACE; ADJUSTABLE; LIGHT GRAY 51180934 51180934
Catalog Description: RS-232 C Serial Interface; Adjustable
