Brand: Wago
WAGO 750-663/000-003 Intrinsically safe 4-channel digital input
Image Disclaimers Message
Brand: Wago
WAGO 750-663/000-003 Intrinsically safe 4-channel digital input
Brand: Wago
WAGO 750-663/000-003 Intrinsically safe 4-channel digital input
Part #:750-663/000-003
SKU #: 2276579
$1428.00/EA
Key Features
Part #:750-663/000-003
SKU #: 2276579
Brand: Wago
Achievable safety classes: SIL 3 per IEC 61508; SIL 3 per IEC 61511; SIL 3 per IEC 62061; Cat. 4, PL e per EN ISO 13849
Color: Multicoloured
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 67.8 mm / 2.669 inch
$1428.00/EA
Specifications
Brand: Wago
Achievable safety classes: SIL 3 per IEC 61508; SIL 3 per IEC 61511; SIL 3 per IEC 62061; Cat. 4, PL e per EN ISO 13849
Color: Multicoloured
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 67.8 mm / 2.669 inch
Height: 100 mm / 3.937 inch
Housing material: Polycarbonate, polyamide 6.6
Intrinsic safety Ex i: Yes
Isolation: 300 VAC system/field
Marking: ATEX/IECEx: II 3 (1) G Ex ec [ia Ga] IIC T4 Gc; II (1) D [Ex ia Da] IIIC; I (M1) [Ex ia Ma] I
Mounting position: Horizontal (standing/lying); vertical
Mounting type: DIN-35 rail
Number of digital inputs: 4
Output current per channel: 0.05 A
Protection type: IP20
Sensor connection: 4 x (Fail-safe input with test pulse)
Short-circuit current: ≤ 25 mA
Signal type: Voltage
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Total number of channels (module): 4
Vibration resistance: 4g per IEC 60068-2-6
Weight: 91.988 g
Width: 24 mm / 0.945 inch
UNSPSC: 32151702
UPC: 04050821531432
WAGO 750-663/000-003 Intrinsically safe 4-channel digital input
Additional Description: WAGO-750-663/000-003 INTRINSICALLY SAFE 4-CHANNEL DIGITAL INPUT; 24 VDC; PROFISAFE V2.0 IPAR; MULTICOLOURED 51264981 V2.0 IPAR; MULTICOLOURED 51264981
Catalog Description: Intrinsically safe 4-channel digital input; 24 VDC; PROFIsafe V2.0 iPar
