Brand: Wago
WAGO 753-602 Power Supply
Image Disclaimers Message
Brand: Wago
WAGO 753-602 Power Supply
Brand: Wago
WAGO 753-602 Power Supply
Part #:753-602
SKU #: 2321660
$36.29/EA
Key Features
Part #:753-602
SKU #: 2321660
Brand: Wago
Amperage Rating: 10 A
Case Material: Polycarbonate/Polyamide 6.6
Input Voltage: 5 VDC
Series: 753
Type: Electronic
$36.29/EA
Specifications
Brand: Wago
Amperage Rating: 10 A
Case Material: Polycarbonate/Polyamide 6.6
Input Voltage: 5 VDC
Series: 753
Type: Electronic
Connection technology: 6 x CAGE CLAMP®
Country of origin: DE
Depth: 2.74 in, 69.8 mm / 2.748 inch
Height: 100 mm / 3.937 inch, 3.93 in
Housing material: Polycarbonate, polyamide 6.6
Mounting position: Horizontal (standing/lying); vertical
Mounting type: 35 mm DIN Rail, DIN-35 rail
Output voltage: 24 VDC
Pluggable connector: Yes
Protection type: IP20
Signal type: Voltage
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Vibration resistance: 4g per IEC 60068-2-6
Weight: 36.500 g
Width: 0.47 in, 12 mm / 0.472 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 32151702
UPC: 04045454394608
WAGO 753-602 Power Supply
WAGO, 753-602, Power Supply, Electronic, Series: 753, 5 VDC Input, 24 VDC Output, 10 A, 35 mm DIN Rail Mounting, Polycarbonate/Polyamide 6.6 Case, 0.47 in Width, 2.74 in Depth, 3.93 in Height
Additional Description: WAGO-753-602 POWER SUPPLY; 24 VDC; - 51180966
Catalog Description: Power Supply; 24 VDC
Item FeaturesFor Marine applications
Item FeaturesRoHS Compliant
